Thunderjet X1602
High cost-effective eco-solvent and ink jet printer
Frontlit&backlit
Car wrap
Banner
THUNDERJET X1602 - Special Features
Mirrored Print Head Configuration
Mirrored print head configuration delivers rich and even solid colors during bi-direction printing. GZ nozzle compensation tech enables uninterrupted printing when a few nozzles clog.
Auto Capping&Wiping System
Auto Capping&Wiping System with aluminum base perfectly cleans the print head nozzle face to achieve excellent printing quality and extend the print head life.
Aluminum beam and pinch rollers
Aluminum beam assures precise carriage movement and long running life. Serried pinch rollers assures accurate and steady media feeding and prevent media wrinkle.
GZ Variable Dot Technology
GZ Variable Dot Technology delivers flawless skin tone, smoother gradient, crisp text and intricate detail without losing speed.
Bulk Ink Supply System
1.5 L ink tanks and ink cartridges assure stable ink supply and reduce downtime. Non-pump system is suitable for both eco-solvent ink and sublimation ink.
IR Drying System
Smart IR drying system works synchronously with printing, not only drying the printing quickly but also saving energy and securing printing.
Technical Specification
| ITEM | SPECIFICATION |
|---|---|
| Model | ThunderJet X1602 |
| Print Head | 2 XP600 print heads |
| Technology | Piezo Variable dot (Greyscale) |
| Ink | C.M.Y.K Eco solvent ink |
| Printing Width | Max. 1600mm |
| Media Type | Coated PP, Vinyl, Film, Banner...... |
| Roll Diameter | Max. 230mm |
| Roll Weight | Max. 20kgs |
| Core Diameter | 3 in (76.2mm) or 2 in (50.8mm) |
| Drying System | Pre, Mid, Post heaters + IR Drying system |
| Printing Speed | Draft 32m2/h Production 23m2/h High-res 15m2/h Photo 13m2/h |
| Data Interface | Gigabit Ethernet |
| Working Environment | Temp.23℃~29℃, Humidity:50%~80% |
| Software | Riprint/PhotoPRINT...+GZ control console |
| Power | 50Hz/AC,220V+10% 3A(printer)+10A(IR Drying system) |
| Installed/Packdge Size | LxWxH(mm):2550x882x1221/ 2830x930x950 |
| G.W./ N.W. | 354kgs/ 204kgs |
Specifications are liable to change without prior notice. The printing speeds are measured in 1.6m width printing.
